Illuminated 65 Moa Ring Tactical Mini 553 Type Red DOT & Green DOT Sight Scope (553)

Full name: Aluminum Alloy with black color tactical mini 553 type red DOT & green DOT sight scope combo.

Model: 553 red DOT & green DOT scope combo, 553 red DOT & green DOT sight combo


Black hood/base/battery cap with black housing
USSOCOM standardized, Type Classified SU-231/PEQ
Dual ARMS throw levers with 7mm raised base
66ft. Submersion rating
A pair of AAA batteries
65MOA ring/1MOA DOT reticle pattern


Optics: Transmission holography - 100% parallax free
Magnification: 1x
Eye Relief: Unlimited
Length/Width/Height: 4.9"x1.8"x2.8" (124x49x71 mm)
Weight: 14.2 oz (400 grams)
Temperature: -40 to 150 F (using AA lithiums); -20 to 140 F (AA Alkaline)
Waterproof: Submersible to 66 ft depth
Sealing: Fogproof internal optics
Color/Finish: Black (non-reflective black on some small components) or Non reflective black with hard coat finish
Adjustment (per click): 0.5 MOA (1/2" at 100 yds)
Adjustment Range: +/- 40 MOA travel
Mount: 1" Picatinny (MIL-STD-1913) rail
Return to Zero: Repeatable to 1 MOA after re-mounting

Heads-Up-Display Window:

Optical Surfaces: Anti-glare coating
Window Dimensions: 1.20" x 0.85" (30 x 23mm)
Front Window Material: 1/8" solid glass
Rear Window Material: Shatter resistant laminate (3/16" thick)
Field of View (100 yds): 30 yds (28m) at a 4" eye relief
Standard Reticle: 65MOA circle with quadrant ticks with 1 MOA aiming DOT


Brightness Adjustment Range: 110, 000: 1 brightest to lowest
Night Vision Brightness Range: 1000: 1 with NV switch engaged
Power Source: 2 x AAA lithium batteries
Battery Life: 1100 continuous hours at nominal setting 12
Brightness Settings: 30 settings with scrolling feature (10 settings for NV use)
Auto Battery Check Indicator: Flashing reticle upon start-up
Auto Shut-down: At 8 hrs- programmable to 4 hrs


-1 x UFC 553 Type Red and Green DOT Sight QD
-2 x AAA batteries
-1 x Instruction Manual
Unit weight: 0.40 kgs
NW: 12.5 kgs
GW: 13.5 kgs
Individual package: Brown papger box with 19*11*8cm size
Packing: 30 units/CTN
Master carton size: 57*33*24 cm.
